High Quality Disposable Injection Needle for Endoscopy manufacturers and suppliers

Disposable Injection Needle for Endoscopy

Short Description:

● Working Length: 120 cm to 230 cm.

● Diameter Options: 1.0/1.8/2.4 mm.

● Needle: Short and sharp with a beveled design.

● Outer tube is made of polytetrafluoroethylene (PTFE) with a smooth surface, ensuring no damage to the endoscope channel during insertion.

Send email to us

Product Detail

Product Tags

Application

Used in conjunction with an endoscope for submucosal injection in the digestive tract

Specification

Model	Diameter D±0.1(mm)	Working Length L±50(mm)	Needle Size (diameter/length)	Working Channel
ZRH-PN-1812-254	Φ1.8	1200	25 G,4mm	≥2.0
ZRH-PN-2418-214	Φ2.4	1800	21 G,4mm	≥2.8
★ZRH-PN-2418-234	Φ2.4	1800	23 G,4mm	≥2.8
ZRH-PN-2418-254	Φ2.4	1800	25 G,4mm	≥2.8
ZRH-PN-2418-216	Φ2.4	1800	21 G,6mm	≥2.8
ZRH-PN-2418-236	Φ2.4	1800	23 G,6mm	≥2.8
ZRH-PN-2418-256	Φ2.4	1800	25 G,6mm	≥2.8
ZRH-PN-2423-214	Φ2.4	2300	21 G,4mm	≥2.8
ZRH-PN-2423-234	Φ2.4	2300	23 G,4mm	≥2.8
ZRH-PN-2423-254	Φ2.4	2300	25 G,4mm	≥2.8
ZRH-PN-2423-216	Φ2.4	2300	21 G,6mm	≥2.8
★ZRH-PN-2423-236	Φ2.4	2300	23 G,6mm	≥2.8
ZRH-PN-2423-256	Φ2.4	2300	25 G,6mm	≥2.8
★ Commonly selected models

Products Description

● Ultra-sharp, precision-ground needle tip for clean incisions.

● Available in a comprehensive range of lengths and gauges.

● Provides clear auditory and haptic feedback for confirmed deployment and retraction.

● High-flow lumen design facilitates effortless injection of viscous fluids, ideal for ESD.

● The ergonomic design of the handle provides a comfortable operating experience, and the needle has clear upper and lower stop points.

● Individually packaged and sterilized.

How the Disposable Endoscopic Needle Works
A endoscopic needle is used to inject fluid into the submucosal space to elevate the lesion away from the underlying muscularis propria and create a less flat target for resection.

Our Endoscopic Needle are widely in EMR or ESD.

Application of EMR/ESD accessories
Accessories needed for EMR operation include injection needle, polypectomy snares, hemoclip and ligation device (if applicable) single-use snare probe could be used for both EMR and ESD operations, it also names all-in-one due to its hybird functions. Ligation device could assist polyp ligate, also used for purse-string-suture under endoscop, the hemoclip is used for endoscopic hemostasis and clamping the wound in GI tract.
